High Reliability Super Luminescent Diode FOG Comonents Standard SLD Luminescent Diode

Brand Name : Liocrebif

Model Number : LKF-SLD

Certification : GJB 9001C-2017

Place of Origin : China

MOQ : 1

Price : 5000-25000CHY

Payment Terms : T/T

Supply Ability : 10000

Delivery Time : 2-4 weeks

Packaging Details : Wooden box/Cardboard box/Container

Color&Classification : LKF-SLD

Brand : LIOCREBIF

Module Type : Gyroscope

Origin Place : China

Application : Fiber optic gyroscope

Output Format : RS422

Contact Now

Essential details
MOQ:1
Specification Number:LKF-SLD
Product Introduction
Product Introduction

SLD is fabricated with high stability of output optical power, high symmetry in the optical spectrum, and high reliability during all working temperature range.

Standard 8-pin butterfly structure is used for compacted hermetic package. The chip temperature can be controlled by external PCB to realize long term stable operation.

Technical Specification

LKF 1310nm SLD

Working Wavelength

1310nm

Spectrum Bandwidth

≥35 nm

Output Power@100mA

200~400 μW

400~800 μW

≥800 μW

Spectrum Ripple

≤0.2 dB

Polarization Extinction Ratio

≤1.2 dB or ≥12 dB

Output Power Variation at Full Temperature

≤3%

TEC Cooling Current

≤700 mA (stable working state at full temperature)

≥1200mA (quick start state)

Package

Type H, 8-pin / Type J, 6-pin

Size

22mm×12.6mm×(7.3~8.0)mm (Type H package)

16.8mm×9mm×5.7mm (Type J package)

Tail Fiber

PM/SM, ≥1m

Working Temperature

-45~+70℃

Storage Temperature

-55~+85℃

Product Code Table

Product code

Power

[um]

Output pigtail

Axis Alignment

Package Type

GHCN01

＞800

125/250 PM

-

H

GHCF02

＞800

125/250 PM

Fast

H

GHCN03

400~800

125/250 PM

-

H

GHCN04

200~400

125/250 PM

-

H

GHLF02

＞800

80/165 PM

Fast

H

GHCS02

＞800

125/250 PM

Slow

H

GHLN01

＞800

80/165 PM

-

H

GJCN03

400~800

125/250 PM

-

J
Key Features

High ReliabilityHigh optical output power

Excellent stability of optical power

High PER and low PER is optional

Lower Electrical power supply

Wide working temperature range

Applications

Fiber Optic Gyroscope (FOG)

Fiber Optic Current Transformer (FOCT)

Optical Coherence Tomography (OCT)

Biomedical Imaging

Other Fiber Optic Sensing

Fig.1 Dimensions Of SLD

H Type

High Reliability Super Luminescent Diode FOG Comonents Standard SLD Luminescent Diode

J Type

High Reliability Super Luminescent Diode FOG Comonents Standard SLD Luminescent Diode
